Descrição
For applications requiring the sonic and practical advantages of integrating the subwoofers into the flying array JBL offers the VRX918S and the VRX915S, two compact, high power, suspendable subwoofer systems using 15 inch and 18 inch Differential Drive® woofers in front loaded vented enclosures. A powered 18 inch option, VRX918SP is also available. The VRX918S was designed specifically for use in arrays with the VRX932LA, as the VRX915S complements perfectly the VRX928LA. Both subwoofers are equipped with a top-mounted, threaded, M20 socket that can receive the optional SS4-BK adjustable pole. WARNING: The VRX928LA is the only system intended for use with the VRX915S when utilizing the SS4-BK.
Especificações
| Especificações Gerais | |
|---|---|
| Frequency Range Hz (-10 dB) | 35 - 250 |
| Resposta de Frequência Hz (±3 dB) | 40 - 250 |
| SPL Máximo (Pico dB) | 126 |
| Nominal Impedance (ohms) | 4 |
| Potência de Saída (W RMS) | 800 |
| Power Rating (W, Peak) | 3200 |
| Sensitivity (dB SPL 1w/1m) | 91 |
| Dimensões | |
| Profundidade (polegadas) | 23.5 |
| Profundidade (mm) | 597 |
| Altura (polegadas) | 19.5 |
| Altura (mm) | 496 |
| Peso (kg) | 26 |
| Peso (lbs) | 57 |
| Largura (polegadas) | 16.5 |
| Largura (mm) | 420 |
| Design | |
| Enclosure | 15 mm - 18 mm, multi ply birch plywood |
| Suspension / Mounting | Top mounted M20 threaded socket for optional pole SS4-BK. Integrated flying hardware for use with array frame VRX-SMAF. 8 M10 fittings. Optional M10 eyebolt kit. |
| Finish | Black DuraFlex™ finish |
| Grille | Powder coated, black, 16-gauge perforated steel with with acoustically transparent foam |
Características
Integral rigging hardwareFor simple connection of VRX928LA line-arrays and optional array frame
Light and compactFor versatility and easy handleability
Durable constructionVRX900 Series enclosures are constructed with premium quality birch plywood. Coated in JBL's rugged DuraFlex™ finish and heavily braced the systems are extremely durable, not to mention rigid and resonance free. The heavy duty steel grilles are internally lined with acoustically transparent foam to provide additional driver protection.
15 inch, 2265G-1 Differential Drive® wooferFor extended low-frequency output
20 mm threaded pole socketFor solid, secure satellite speaker mounting
